Ultrasonic point sealer QPB-01 for ironer guide tape welding / Cordless type
Ultrasonic point sealer QPB-01 for ironer guide tape welding / Cordless type
- Easy to operate
Tapes can be welded by squeezing the handpiece for a few seconds.
- No warm-up time required
It is ready to use as soon as you turn it on.
- Ultrasonic welding
The horn generates ultrasonic vibrations.
Ultrasonic vibrations generate frictional heat to weld materials.
It is safe as the horn doesn't generate heat.
Consumables are not used.
- The welded joints are smooth and strong.
- The cordless unit is easy to carry and operate
- Made in Japan
Download
Demonstration Videos
Features
Easy to operate
Tapes can be welded by squeezing the handpiece for a few seconds.
No warm-up time required
It is ready to use as soon as you turn it on.
Ultrasonic welding
It is safe as the horn doesn't generate heat.
Consumables are not used.
Welded joints are smooth and strong
Cordless
When fully charged, generally you can seal about 5000 times. (In the case of QPB-01, timer 3)
Shape of seal
A half-moon shaped weld mark appears after sealing.
100～240V
100V～240V(AC50/60Hz )
Made in Japan
Made in Nagoya, Japan.
Specifications
| Product Name | Ultrasonic point sealer QPB-01 [Cordless] |
|---|---|
| Product Number | QPB-01 |
| Oscillation frequency | 57kHz |
| Max. output | 20W |
| Max. power consumption | 40VA |
| Power Source | 100V～240V AC 50/60Hz |
| Dimensions / unit | W140×D183×H66mm |
| Dimensions / hand piece | W36×D125×H54mm |
| Weight / unit | 1000g |
| Weight / hand piece | 200g |
| Other options | Cordless |
